Semi Automotic Canning System
| (Size:W*L*H) | 1.20x 0.73 x1.7mm | |||
| (Weight) | 133KG | |||
| Packing Size （L*W*H) | 0.86x1.17x1.93M | |||
| (Gross Weight) | 232KG | |||
| Capacity） | 500PCS/STATION|1 STATION | |||
| (Power) | Singel Phase 110V-240VAC 50/60Hz is default | |||
| (Power consumption) | 800W | |||
| (Main Material) | AISI304, Aluminum Alloy and POM | |||
| (Beer Source Requirement) | Temperature: 30.2 - 32F (-1 to 0C) Carbonation: 2.4 to 2.7 volumes CO2 (4.6 to 5.2 g/L CO2) Pressure：22psi（0.15MPa） Connection: 1.5" Tri-clamp | |||
| (CO2 Regulator) | 58-65 psi（0.4MPa-0.45Mpa） from plant system connected to canning system with 3/8“OD barbed fitting 3/8：58-65 psi(0.4MPa-0.45Mpa) | |||
| (Air Regulator） | 87-102 psi（0.6MPa-0.7Mpa） from plant system connected to canning system with 3/8“OD barbed fitting 3/8：87-102 psi（0.6MPa-0.7Mpa） | |||
| (Time setting way) | Siemens PLC 200 smart and IEV3 Touch Screen | |||
| (Dissolved Oxygen) | ≤50ppb | |||
| (Can type) | Flash Boy FBCS1-1 can be configured for nearly all standard can sizes! Change over between different can dimensions is a snap, requiring only a few simple tools and less than 30 minutes. | |||
| (Rinse function) | 3S/pc（unadjustable） | |||
| (Spray function) | 2S/pc（adjustable） | |||
